Teac TN-4D-SE/WA Analog Turntable
пянз тоглуулагч
#102857022
(0 сэтгэгдэл)
Price section
Үнэ
1,999,900₮
Teac TN-4D-SE/WA Analog Turntable
пянз тоглуулагч
Үнэ
1,999,900₮
| Type | Direct Drive |
| Motor | Brush-less DC Motor |
| Rotation Speeds | 33-⅓ rpm, 45 rpm |
| Wow-and-Flutters | 0.1% |
| S/N Ratio | 67dB or higher (A-weighted, 20kHz LPF) |
| Turntable (Platter) | |
| Material | Aluminium Die-cast |
| Diameter | 30cm |
| Tone-arm section | |
| Type | S-shaped, Static-balanced |
| Effective Length | 223mm |
| Needle Pressure Range | 0g to 5.0g |
| Compatible Cartridge Weight | 4.0g to 13.0g 14g to 23g (including Head-shell) |
| Head-shell and Cartridge sections | |
| Type | MM-type (SUMIKO Oyster factory installed) |
| Output Voltage | 4.0mV (1kHz) |
| Needle Pressure | 1.5 to 2.5g (appropriate value: 2.3g) |
| Weight | 5.3g |
| Head-shell weight | 10g (including nuts, screws, and wires) |
| Compatible Stylus | Styluses for SUMIKO Oyster |
| Analog Outputs | |
| Connector | RCA Pin jack × 1 pair (PHONO/LINE switchable) |
| Output Voltage | |
| PHONO | 4.0mV (1kHz) |
| LINE | 224mV (–13dBV) |
| USB Output | |
| Connector | USB B-type (DC 5V 100mA USB Bus power required) |
| Audio Format | PCM, 8k/11.025k/16k/22.5k/32k/44.1k/48kHz, 16bit |
| Operating Power | AC 100 to 240V, 50/60Hz |
| Power Consumption | 2W |
| Standby Power | 0.5W or less |
| Overall Dimensions (W×H×D) | 420 × 117 × 356 mm / 16.5" × 4.6" × 14.0" |
| Weight | Approx. 6.1kg / 13.5 lbs. |
| Included Accessories | Felt Mat, EP Adapter, Counter Weight, Head-shell (SUMIKO Oyster installed), Platter, Dust Cover, Hinges × 2, RCA Audio cable with GND terminal, AC Adapter (GPE036W-24015), Owner's Manual (including Warranty Card) |
